Never content, Lumin has been constantly been evaluating its streamers to see if there was any possible way to beat them. It's taken years, but finally Lumin is ready to reveal streaming's new cutting edge.
Re-engineered throughout
LUMIN X1 makes improvements in every possible location:
New processor delivers native DSD512 & PCM768 playback
Dual Mono design throughout maximises channel separation
Dual ES9038Pro SABRE DACs featuring 140dB dynamic range
Fully balanced layout with high-quality components
Femto Clock System with precision FPGA distribution
Output connectors coupled with dual Lundahl LL7401 output transformers
New Output Buffer design
Dual Mono dual stage linear regulator
Optical Network provides complete isolation from network digital noise
USB Digital Audio Output supports Native DSD512
Entirely new power supply
New solid billet CNC casing design
Separate digital & analogue circuitry
Low-noise linear regulator
New 9-pin output connector
Available as an upgrade for existing S1 / A1 / T1 customers
Specification
DSD support: Up to DSD512 22.6mhz, 1-bit PCM support: Up to 768khz, 16–32-bit, stereo Analog output stage: Dual ESS SABRE32 ES9038PRO DAC chips Upsampling rates & bit depths: DSD128 upsampling option for all files PCM 384kHz upsampling option for all files
Digital output stage
USB: Native DSD512 support,PCM 44.1–768kHz, 16–32-bit, stereo BNC S/PDIF: PCM 44.1khz–192khz, 16–24-bit; DSD (DoP, DSD over PCM) 2.8mhz, 1-bit Optical network: Industry-standard SFP, 1000base-T Eigabit Ethernet. Adapter may be needed for your particular switch/cables. Use simultaneously with RJ45
